Original price was: $82,000.00.$77,246.00Current price is: $77,246.00.
| Parameters | Standard Specifications |
|---|---|
| X, Y, Z Working Area | 8000*2500 mm|26*8ft |
| Optional Working Area | 1300*900|4*4ft 1500*3000|5*10ft 2000*3000|6*10ft 2000*4000|6*13ft 2000*6000|6*20ft |
| Laser Power | 20 kW |
| X, Y, Z Traveling Positioning Accuracy | ±0.02 mm / 2000 mm |
| Max Cutting Speed | 35 m/min (depending on material and thickness) |
| Water Cooling System | Constant temperature industrial chiller |
| Max Rapid Travel Rate | 100 m/min |
| Fiber laser cutting machine with smart auto obstacle avoidance ensures safer cutting, prevents collisions, and boosts efficiency. |  |
 |
 |
 |
High stability bed To optimize the design of the sectional welding lathe bed.Lathe bed in the middle of reinforcing bar, improves the lathe bed stability. The lathe weighs 2.2 T to ensure the accuracy and durability of the equipment. |
| High light and rigidity Aerospace grade aluminum light quality, high speed.Beam as a whole by the finite element analysis optimization of high rigidity. |
|
 |
 |
|
Long-lifespan laser sources, available in MAX, Raycus, IPG, or RECI options, ensuring stable performance, high cutting efficiency, and reliable operation for diverse metal processing needs. |
| Original gears and guide rails World famous imported brand precision linear guides and imported gear racks |
|
 |
 |
|
Fiber laser head The laser head body is increased anti-collision function and can be adapted with a variety of fiber laser |
| Industrial water chillers The constant temperature of water chiller can keep the laser power stable, work more stable and fast |
|
 |
 |
|
The motor adopt lead shine servo motor |
| Taiwan Hiwin Linear Guide Rail Adopted Taiwan Hiwin linear guide rail, high positioning accuracy, scroll guide, reduce wear to maintain accuracy for a longer time. | |
 |
Heavy Plate and Large Sheet Fabrication – The BCM8025F 20kW fiber laser cutting machine handles oversized carbon steel, stainless steel, aluminum, copper, and brass plates with precision, delivering smooth edges, minimal material waste, and high throughput for industrial workshops and metal fabrication projects.
Automotive and Transportation Industry – Efficiently cuts large automotive body panels, chassis components, and precision metal parts for trucks, buses, and other vehicles, offering consistent accuracy and fast processing suitable for heavy-duty industrial fiber laser cutting machines.
Aerospace and Aviation Components – Produces large, lightweight, and high-precision metal components for aircraft, drones, and spacecraft applications, leveraging the BCM8025F’s high power and large-format cutting capabilities.
Custom Industrial Structures and Signage – Cuts intricate designs, logos, and patterns on oversized metal sheets for custom furniture, decorative metalworks, and industrial signage, ideal for CNC fiber laser cutting applications requiring both size and precision.
Electronics, Panels, and Enclosures – Fabricates large enclosures, control panels, and precision components with tight tolerances, benefiting from the high-speed, reliable, and accurate cutting of thick metal sheets.
Industrial Equipment and Heavy Machinery Manufacturing – Processes structural metal parts, machinery components, and production line elements with fast, stable, and durable fiber laser cutting, supporting high-volume industrial production.
The BCM8025F fiber laser cutting machine provides a reliable, high-power, and cost-effective solution for industries requiring large-format metal processing, heavy plate cutting, and complex shapes, making it ideal for CNC metal laser cutting, industrial fabrication, automotive, aerospace, and other heavy-duty applications.
| Laser Power | Carbon Steel (Max Thickness) | Stainless Steel (Max Thickness) | Aluminum (Max Thickness) |
|---|---|---|---|
| 1500W | ≤ 14 mm | ≤ 6 mm | ≤ 5 mm |
| 2000W | ≤ 16 mm | ≤ 8 mm | ≤ 6 mm |
| 3000W | ≤ 20 mm | ≤ 10 mm | ≤ 8 mm |
| 4000W | ≤ 25 mm | ≤ 12 mm | ≤ 10 mm |
| 6000W | ≤ 30 mm | ≤ 16 mm | ≤ 14 mm |
| 8000W | ≤ 40 mm | ≤ 20 mm | ≤ 18 mm |
| 12000W | ≤ 50 mm | ≤ 30 mm | ≤ 25 mm |
| 20000W | ≤ 70 mm | ≤ 40 mm | ≤ 35 mm |
1. What is the BCM8025F fiber laser cutting machine?
The BCM8025F is a 20kW high-power CNC fiber laser cutting machine designed for large metal sheets and heavy plates. It delivers precise, fast, and efficient cutting for industrial fabrication, automotive, aerospace, and structural steel applications.
2. What types of metals can the BCM8025F cut?
It can process a wide range of metals, including:
3. What thickness can it cut?
The BCM8025F 20kW fiber laser cutting machine can cut:
4. What industries benefit most from the BCM8025F?
5. What advantages does the BCM8025F have over traditional cutting methods?
6. Which software and file formats are supported?
Supports most CAD/CAM software and file types, including DXF, PLT, AI, SVG, and G-code. Includes CNC nesting software for large sheets and heavy plate optimization.
7. What assist gases are recommended?
8. What is the expected lifespan of the BCM8025F?
9. What maintenance is required?
10. Is operator training provided?
Yes. Installation support, training manuals, videos, and on-site or remote training are available to ensure safe and efficient operation.
11. What safety precautions should be followed?
12. How to choose BCM8025F for your workshop?
At BCAMCNC, we provide comprehensive service and support for the BCM8025F 20kW fiber laser cutting machine, ensuring smooth operation, high productivity, and reliable performance for large-format and heavy plate cutting applications. Our offerings include:
